Sanitary Pressure Sensors are used widely in the Food, Dairy, Beverage, Pharmaceutical, Nutritional, Biotech and all other Sanitary Process industries to provide an electrical measurement of process fluid pressure. Sensors are available for most industry standard electrical signals and standard Tri-Clamp® Ends. GVC Direct, Inc. offers a wide range of Sanitary Sensors that meet all FDA and other High-Purity requirements. GVC Direct, Inc. offers validation documentation on all Sanitary Sensors when requested at time of order.
Wiring | Color Code | V | mA |
---|---|---|---|
1 | Red | +Excitation | +Excitation/Signal |
2 | Black | -Excitation/Signal | -Excitation/Signal |
3 | Green | +Signal | NC |
Grnd. | Shield/White | Gnd | Gnd |
