Stacking Kit type Heavy Series Block Style Hangers are very useful when supporting more than one line at time and strong anchoring of the pipe or tube is required. The Stacking Kit can be combined with the Heavy Series and Double Heavy Mount Hangers. The Kit includes a Safety Plate, Bolts and Clamp Halves allowing two Hangers to be stacked and installed. Heavy Block Style Hanger Anchors clamp the pipe or tube firmly within the two halves. Materials of Construction can be tailored in Block Style Hangers in order to support extremely hot or cold fluids. Block Halves are available in Black Polypropylene, high temperature Santoprene, and Aluminum. Block Style Hardware is available in plain Carbon Steel. Stacked Block Style Hangers are available to support a wide range of pipe and tube sizes ranging from ¼ tube to 8 pipe. Be sure to contact us with any questions.
Size | D | W | H | K | O | Bolt Size |
---|---|---|---|---|---|---|
1 1/4" Pipe | 1.660" | 4.5" | 3.5" | 1.75" | 0.125" | 7/16-14" |
1 3/4" Tube | 1.750" | 4.5" | 3.5" | 1.75" | 0.125" | 7/16-14" |
1 1/2" Pipe | 1.900" | 4.5" | 3.5" | 1.75" | 0.125" | 7/16-14" |
2" Tube | 2.000" | 4.5" | 3.5" | 1.75" | 0.125" | 7/16-14" |
2 1/4" Tube | 2.250" | 4.5" | 3.5" | 1.75" | 0.125" | 7/16-14" |
2" Pipe | 2.375" | 4.5" | 3.5" | 1.75" | 0.125" | 7/16-14" |
2 1/2" Tube | 2.500" | 4.5" | 3.5" | 1.75" | 0.125" | 7/16-14" |
2 3/4" Tube | 2.750" | 4.5" | 3.5" | 1.75" | 0.125" | 7/16-14" |
